TERRARIUM COMMERCIAL SERIES
Terrariums are advanced greenhouse based plant production systems that use automation controllers, sensors, growing recipes, and artificial intelligence to grow fresh food on a consistent basis. The Terrarium Series of Plant Factories enable growers to achieve year-round consistent vegetable production. The primary goal of the Terrarium structure is to maintain a comfortable indoor climate while maximizing natural resources such as sunlight.
Wind flow. micro climate, natural sunlight, energy management and crop selection are important design – onside rations in the success of a Plant Factory
These structures are aerated to enable crops to be grown in partially controlled climatic conditions.
They are constructed of a translucent material that allows sunlight to pass through films for photosynthesis.
This format produces higher yields, better quality and consistent produce.
Each model of the Terrarium series has been carefully designed for optimum energy utilization.
They ensure higher food production in relation to the effort required
MONITORING CONSOLE & MOBILE APP
The Terrarium comes with a tablet to monitor and control the Plant grow operations end -to-end. The Axalyn mobile App can be used on Desktops, Tablets and Mobile devices from anywhere anytime for remote monitoring.
Benefits
Water conservation of upto 90% when compared to tradi tional farming
Achieve optimal thermal balance through Fan and Pad system
Hygienic produce free from toxic chemicals & pesticides
Crops grown in pure water with nutrient supplements
Excellent ventilation to maintain the inside microclimate
Allows cultivation of a wide variety of crops
Maintains hot and humid levels through Fogging or Heating systems
Optimal sealing to protect from heave rains and winds
Protection from pest and disease infesta tions
Energy savings due to effective usage of available natural resources
Terrarium Mega
Specifications
Area: 11000 sq ft
Plant capacity: 30,000 plants
Multi controller (Irrigation & Climate)
Nutrient Dispenser and Dosing Controller
Grow Light Controller
Solar Panel
Reverse Osmosis: 1000 Liters/hour
High pressure Fogging system
Germination propagation tables with trays
NFT vertical channels with predrilled holes – 2′ net cups
Dutch bucket system – 3″ net cups
Weedmat
Grow methods – NFT system, Ebb and flow, Grow bags,
Aeroponic towers
Plants grown: Turmeric, Green chilly, Cherry tomato,
Bell pepper, Basil, Swiss Chard. Cucumber, Black carrot,
Leek, Lettuce etc..
1 NTF Frame Contains 8 Channel (4 feet NFT with 8 Holes)
Holes CC 5-6 inch
Solar Panel 72 Cells/335 W x 6 No
NFT Frames: 90
NFT Channels: 1140
NFT Plants: 30,000
Dutch Bucket: As per requirement
Dutch Frames: As per requirement
10,000 Ltr Tanks: 1
3,000 Lts Tanks: 2
25 Ltr Tanks: 4
Terrarium Tera
Specifications
Area: 22000 sq ft
Plant capacity: 60,000 plants
Multi controller (Irrigation & Climate)
Nutrient Dispenser and Dosing Controller
Grow Light Controller
Solar Panel
Reverse Osmosis: 2000 Liters/hour
High pressure Fogging system
Germination propagation tables with trays
NFT vertical channels with predrilled holes – 2′ net cups
Dutch bucket system – 3′ net cups
Weedmat
Grow methods: NFT system, Ebb and flow, Grow bags,
Aeroponic towers
Plants grown: Turmeric, Green chilly, Cherry tomato,
Bell pepper, Basil, Swiss Chard, Cucumber, Black carrot,
Leek, Lettuce etc..
1 NTF Frame Contains 8 Channel (4 feet NFT with 8 Holes)
Holes CC 5-6 inch Solar Panel 72 Cells/335 W x 6 No
NFT Frames: 180
NFT Channels: 2,280
NFT Plants: 60,000
Dutch Bucket: As per requirement
Dutch Frames: As per requirement
10,000 Ltr Tanks: 2
3,000 Lts Tanks: 4
25 Ltr Tanks: 8
Terrarium Giga
Specifications
Area: 44000 sq ft
Plant capacity: 1,20,000 plants
Multi controller (Irrigation & Climate)
Nutrient Dispenser and Dosing Controller
Grow Light Controller
Solar Panel
Reverse Osmosis: 4,000 Liters/hour
High pressure Fogging system
Germination propagation tables with trays
NFT vertical channels with predrilled holes – 2′ net cups
Dutch bucket system – 3* net cups
Weedmat
Grow methods: NFT system, Ebb and flow, Grow bags,
Aeroponic towers
Plants grown: Turmeric, Green chilly, Cherry tomato,
Bell pepper, Basil, Swiss Chard, Cucumber, Black carrot,
Leek, Lettuce etc..
1 NTF Frame Contains 8 Channel (4 feet NFT with 8 Holes)
Holes CC 5-6 inch
Solar Panel 72 Cells/335 W xt 6 No
NET Frames – 360
NFT Channels – 4,560
NFT Plants – 1,20,000
Dutch Bucket – As per requirement
Dutch Frames – As per requirement
10,000 Ltr Tanks – 4
3,000 Lts Tanks – 8
25 Ltr Tanks: 16
